FLIR IRW-6PS IR Window, 3.6 x 5.9″, stainless steel
FLIR IRW-6PS infrared inspection window. 3.6 x 5.9 in (9.14 x 15 cm) viewing aperture for inspecting energized equipment through a closed panel.
$649.00 USD
Prices in USD, shipping not included.
Shipping cost, lead time and availability are confirmed in your quotation.
Specifications
- Infrared inspection window with a rectangular viewing area for thermographic, UV and visual inspection of energized electrical equipment without opening the panel door
- Fail-safe design that meets the IP2x standard for safe maximum hole size; recommended for indoor applications
- Impact-resistant polymer optic with fixed, stable transmission; lockable covers protect the viewing pane from debris, dust and impact
- Compatible with acids, alkalis, UV, moisture, humidity, vibration and high-frequency noise
- Aperture dimensions: 5.9 x 3.6 in (15 x 9.1 cm); overall dimensions 8.6 x 6.3 in (21.8 x 16 cm)
- Optic temperature range: -40 to 617°F (-40 to 325°C); maximum operating temperature -40 to 523°F (-40 to 273°C)
- Transmits midwave IR, longwave IR, UV and visible light
- Suitable for medium/high voltage applications, any voltage range; automatically grounded
- Material: powder-coated stainless steel body, stainless steel reinforcing grill, UL 746 compliant polymer optic
- Environment rating: IP65 / NEMA 4x
- Ratings include UL 50V, 50E, 756C, UL 1558, UL 508A, CSA C22.2 No. 14-13, Lloyds of London, ABS and DNV P261.1E
- In the box: IR window, fitting template, IR window label, fitting hardware
Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
