Mark-10 M2-500 Series 2 Economical Digital Force Gauge, 500 x 0.5 lbF
Mark-10 M2-500 Series 2 economical digital force gauge. Capacity 500 lbF (2500 N), 500 Hz sampling rate.
$641.25 USD
Prices in USD, shipping not included.
Shipping cost, lead time and availability are confirmed in your quotation.
Specifications
- Digital force gauge for basic tension and compression testing in production and laboratory use
- Shows the current, peak tension or peak compression reading on a backlit graphic LCD
- Calculates peak tension and compression values
- Three selectable units of measurement
- Ultra-compact, ergonomic housing
- Configurable default measurement unit and mode
- Large backlit graphic display with auto-dimming
- Powered by rechargeable battery or AC adapter
- Reversible housing for alternate load cell orientation
- Capacity x resolution: 500 x 0.5 lbF 250 x 0.2 kgF 2500 x 2 N
- Accuracy: ±0.5% of full scale
- Sampling rate: 500 Hz
- Safe overload: 200% of full scale (display shows "OVER" at 110% and above)
- Thread: 5⁄16-18 UNC
- Dimensions: 4.76 x 2.53 x 1.5" (120.9 x 64.3 x 38.1 mm)
- Weight: 0.9 lbs (0.41 kg)
- Power: rechargeable 8.4 V NiMH battery or AC adapter (100 to 240 V AC, 50 to 60 Hz, 0.3 A); battery life up to 7 hours with backlight on, 24 hours with backlight off
- In the box: force gauge, certificate of conformance, battery, AC adapter
Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
