Mark-10 M3-012 Series 3 Digital Force Gauge, 0.12 x 0.0001 lbF
Mark-10 M3-012 Series 3 digital force gauge. Capacity 0.12 lbF (0.5 N), 2000 Hz sampling rate.
$1,615.00 USD
Prices in USD, shipping not included.
Shipping cost, lead time and availability are confirmed in your quotation.
Specifications
- Digital force gauge for tension and compression testing in laboratory and industrial environments
- Reversible aluminum housing allows handheld use or test stand mounting
- Overload protection to 200% of capacity
- USB data output of continuous or individual data points
- Ultra-compact size
- Large backlit graphic display
- Programmable set points with pass/fail indicators
- Live load bar graph with set point markers
- Peak readings and set points always displayed
- Configurable audio alarms and key tones
- Three selectable units of measurement
- Capacity x resolution: 0.12 x 0.0001 lbF 50 x 0.05 gF 0.5 x 0.0005 N
- Accuracy: ±0.3% of full scale
- Sampling rate: 2000 Hz
- Safe overload: 200% of full scale (display shows "OVER" at 110% and above)
- Load cell deflection: 0.005 (0.13)
- Thread: #10-32 UNF
- Dimensions: 2.53 x 1.5 x 3.9" (64.3 x 38.1 x 99.1 mm)
- Weight: 0.7 lbs (0.33 kg)
- Power: rechargeable 8.4 V NiMH battery or AC adapter (100 to 240 V AC, 50 to 60 Hz, 0.3 A); battery life up to 7 hours with backlight on, 24 hours with backlight off
- In the box: force gauge, certificate of calibration without data, extension rod, cone attachment, chisel attachment, V-groove attachment, flat attachment, hook attachment, USB cable, carrying case, battery, AC adapter
Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
