Mitutoyo 192-672-10 Digimatic multi-function height gauge, 0-24 / 0-600 mm
Mitutoyo 192-672-10 Series 192 Digimatic multi-function height gauge. Range 0-24 in (0-600 mm) with SPC data output.
$3,211.00 USD
Prices in USD, shipping not included.
Shipping cost, lead time and availability are confirmed in your quotation.
Specifications
- Series 192 multi-function Digimatic height gauge with SPC data output
- Displays in inches or metric units; range 0 to 24" (0-600 mm)
- LCD digital readout with selectable resolution of 0.0005" (0.01 mm) or 0.0002" (0.005 mm)
- Carbide-tipped long scriber provided; rigid construction for repeatable measurement
- Coarse/fine feed switching
- Optional bi-directional touch-signal probe measures steps, inside width and outside width
- Functions: zero-setting, ABS/INC switching, two presets, probe tip diameter compensation, -/+ switching, power on/off, data hold, data output, inch/mm conversion
- Applications: mechanical engineering, metalworks, metrology, machining
- Display: LCD, 7 digits, character height 11 mm; max. response speed 500 mm/s
- Battery: SR44 (1 pc.), approx. 2000 hours under normal use
- Alarms: low voltage, counting value composition error
- Scriber: carbide-tipped scriber (905201) and scriber clamp (901385)
- In the box: height gauge, battery
Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
