Mitutoyo 209-945 Series 209 Digimatic Internal Caliper Gauge, 0.59 to 2.56", SAE/Metric

Mitutoyo

Mitutoyo 209-945 Series 209 Digimatic Internal Caliper Gauge, 0.59 to 2.56″, SAE/Metric

Mitutoyo 209-945 Series 209 digimatic internal caliper gauge. Range 0.59 to 2.56" (15 to 65 mm).

$921.05 USD

Prices in USD, shipping not included.
Shipping cost, lead time and availability are confirmed in your quotation.

Ask about this item How ordering works

TSA SKU
TSA_72102865
Category
Calipers

Specifications

  • Digimatic internal caliper gauge for measuring the inside dimension of tubes, grooves and similar features
  • Long jaws fit into tight spaces; LCD readout
  • Functions include zero-set, preset, MAX/MIN and data hold
  • Data output for SPC analysis; powers off automatically to save battery
  • IP63-rated housing protects against dust and water
  • Measurement range: 0.59 to 2.56" (15 to 65 mm)
  • Accuracy: 0.002" (0.06 mm)
  • Resolution: 0.001" (0.02 mm)
  • Measuring force: 0.7 to 1.7 N
  • Measuring contact: ball, 0.06" (1.5 mm) diameter
  • Power: 1 x AA battery, approx. 350 hours
  • Weight: 14.6 oz (415 g)
  • Compatible accessory (sold separately): KPL1961-09 SPC Adapter
  • In the box: caliper gauge, inspection certificate

Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
