Mitutoyo 331-363-32 Spline Micrometer with SPC, 2 to 3″/ 50.8 to 76.2 mm, Type B
Mitutoyo 331-363-32 spline micrometer (Type B) with SPC output. Measures grooves and shaped parts over 2 to 3" / 50.8 to 76.2 mm with IP65 protection.
$601.64 USD
Prices in USD, shipping not included.
Shipping cost, lead time and availability are confirmed in your quotation.
Specifications
- Digimatic spline micrometer with inch/metric conversion for measuring grooves, splined shafts, slots, keyways and other shaped parts
- Replaces the earlier model 331-363-30
- Type B with a 2 mm measuring face
- Carbide-tipped measuring faces
- Ratchet stop for constant measuring force
- SPC data output
- Non-slip grip finish
- IP65 water and dust protection
- Range: 2 to 3" / 50.8 to 76.2 mm
- Accuracy: ±.0001"
- Resolution: .00005"/0.001 mm
- Flatness: .000012"
- Display: LCD
- Power: 1 x SR44 battery, approx. 2.4 years under normal use
- In the box: micrometer, battery, standard bar, case
Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
