Phase II PHT-6001 UCI Portable Hardness Tester with 1kg Manual Probe

Specifications

• Hand-held non-destructive portable hardness tester combining UCI (ultrasonic) and Leeb (dynamic) methods in one unit
• Handles small or thin work down to 2 mm (0.08 in) thickness as well as large parts
• Suited to surfaces with Ra below 125 uin
• Shows Rockwell, Brinell and Vickers conversions on the display
• Memory with USB output; statistical software supplied (data can be saved in Word or Excel)
• Manual UCI probes available in 1 kg, 2 kg, 5 kg and 10 kg; optional motorized probes 0.30 kg, 0.80 kg and 1 kgf; Leeb impact devices D, DC, D+15, G and DL available
• Hardness range: HRC 20.3-70; HRB 61-85.6; HV 80-1599; HB 76-618
• Scales: Rockwell C (HRC), Rockwell B (HRB), Rockwell A (HRA), Brinell (HB), Vickers (HV), Leeb (HLD)
• Tolerance: +/-3.0% deviation of average from the reference value of the hardness test block, minimum 5 tests
• Surface roughness requirement: Ra < 3.2 um (Ra < 125 uin)
• Loading force: 1 kgf (10 N)
• Probe diameter 22 mm; length 154 mm; oscillating rod diameter 2.4 mm
• Minimum sample weight 0.3 kg (0.66 lbs); minimum sample thickness 2 mm (0.08 in)
• Display: color LCD with adjustable backlight; data memory 2000 groups of measured data and 20 groups of calibration data
• Data output: USB, cable supplied
• Power: rechargeable lithium battery, 4.2 V, 4800 mAh; about 6 hours use (no backlight), about 8 hours recharge; auto power off after 5 minutes
• Unit dimensions 7.0 x 3.1 x 1.1 in (160 x 80 x 30 mm); net weight 2 lbs with probe
• In the box: 1kg Manual probe

Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
