Shimpo FGE-2XY digital force gauge, 32oz/2lb/1000g/10.00N
Shimpo FGE-2XY digital force gauge. 32oz/2lb/1000g/10.00N capacity with ±0.2% F.S. accuracy and 1000 Hz sampling.
$625.50 USD
Prices in USD, shipping not included.
Shipping cost, lead time and availability are confirmed in your quotation.
Specifications
- Handheld digital force gauge for compression and tension testing, including push-pull testing
- Records the peak value with a single button press; one button changes the unit of measure
- 180° reversible display and dual printed keypad, for handheld use or mounting upside down on a test stand
- Variable display response rate; 1 million operation load cell with overload protection
- Die cast aluminum housing; powered by rechargeable battery or AC line voltage
- Typical uses: wire pull and crimps, trigger pull, springs, adhesives, blister packs, syringe plungers, medical components, ergonomic testing
- Capacity: 32oz/2lb/1000g/10.00N
- Accuracy: ±0.2% F.S.
- Overload capacity: 200% of F.S.
- Sampling rate: 1000 Hz
- Display: 4-digit LCD, 0.5 in (12 mm) high, reversible by push-button, minus sign for tension; update rate 0.05, 0.1, 0.2, 0.3, 0.5 or 1 s
- Power: rechargeable Ni-MH battery or AC adapter/charger
- Dimensions: 5.8 x 3 x 1.5 in (147 x 75 x 38 mm); weight 1 lb (450 g)
- In the box: digital force gauge, 8 attachments (hook, chisel, flat tip, notched tip, hanger, cone tip, thread adapter, extension rod), AC adapter/charger, carrying case
Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
