Mitutoyo 526-124-20 Mechanical Dial Bore Gauge for Extra-Small Holes, 7 to 10 mm, 2-point
Mitutoyo 526-124-20 mechanical dial bore gauge. 2-point design for holes from 7 to 10 mm.
$528.31 USD
Prices in USD, shipping not included.
Shipping cost, lead time and availability are confirmed in your quotation.
Specifications
- Mechanical bore gauge for measuring the diameter of extra-small holes
- 2-point design with 6 anvils and 1 needle
- Clear, easy-to-read dial (2019SB-10)
- Converts radial displacement of the split-ball contact into axial displacement of the measuring rod
- Compatible with the 215-120-10 bore gauge stand (not included) for measuring multiple small holes
- Measuring range: 7 to 10 mm
- Graduation: 0.001 mm
- Accuracy: 4 μm
- Indication stability: 2 μm
- Maximum probe depth: 56 mm
- Unit: metric
- In the box: mechanical dial bore gauge
Specifications are provided by the manufacturer and may change. Please confirm the exact model in your quote request.
